Description
|
Parameter |
Value |
|
|
Camera |
||
|
Image Sensor |
1/2.8″ CMOS, 8.46MP |
|
|
Optical Zoom |
12x |
|
|
Focal |
f=3.4mm ~ 40.3mm |
|
|
Iris |
F1.8~ F3.6 |
|
|
HFOV |
81°~7.6° |
|
|
Image |
Auto Focus, Auto Exposure, Auto White Balance |
|
|
SNR |
>55dB |
|
|
BLC/WDR |
Support |
|
|
PTZ |
||
|
Pan |
-130°~ +130°; 0.2° ~ 87°/s |
|
|
Tilt |
-30° ~ +90°; 0.2° ~ 67°/s |
|
|
Preset Number |
64 |
|
|
Menu |
Support |
|
|
Interface |
||
|
HDMI 2.0 |
1 channel HDMI 2.0, 4KP60/P50/P30/P25, 1080P60/P50/P30/P25, 1080160/150, 720P60/P50 |
|
|
Network |
RJ45 (10M/100M), POE; 4KP60/P50/P30/P25, 1080P60/P50/P30/P25, 720P60/P50 Image Compression: H.264/H.265 |
|
|
USB 2.0 |
1 channel USB2.0; UVC 1.1; 1. 4KP30/P25, 1080P30/P25, 720P30/P25, 360P30/P25; 2. Image Compression: H.264/MJPEG |
|
|
3G-SDI (Optional) |
1 x 3G-SDI(Optional); support 1080P60/P50/P30/P25, 1080160/150, 720P60/P50 |
|
|
Audio Input |
1 channel LINE IN, 3.5mm |
|
|
Control Interface |
1 channel RS-232 IN, 1 channel RS-232 OUT |
|
|
DIP Switch |
Rotating DIP switch to set video format |
|
|
General |
||
|
Control Protocol |
VISCA |
|
|
Power |
DC12V, <18W |
|
|
Operating Temperature |
0°C~ 40°C |
|
|
Storage Temperature |
-20°C~ +60°C |
|
|
Dimensions(LXWXH) |
245mmx145mmx165mm |
|
|
Weight |
< 2kg |
|
