Description
KF
| Parameter | Value |
|---|---|
| WLAN Standard | IEEE802.11ac, IEEE802.11a, IEEE802.11g, IEEE802.11b |
| RF Frequency Bands | 5GHz UNII |
| Max Transmission Power | 27dBm |
| Antenna Type | Four built-in 5dBi antennas |
Power
| Parameter | Value |
|---|---|
| Supply Type | Power Over Ethernet, 802.3at, DC 12V 1.5A |
| Supply Voltage (Power Consumption) | ≤13W |
Network
| Parameter | Value |
|---|---|
| Interface | 1× Gigabit WAN/POE Port, 1× Gigabit LAN Port |
| Link Speed | 1200Mbps |
| Networking Addressing | DHCP or Manual IP address |
| Cable Length | 100m (max) |
| Cable Type | ≥ Cat5e (shielded / unshielded) |
| Connector Type | 1× RJ45 |
| Connector LED | WAN/POE Port (UP LED), LAN Port (Down LED) |
User Interface
| Parameter | Value |
|---|---|
| LED Status Indication | Power, Network Audio, Wireless (Yellow / Blue) |
| Reset | Push button for Factory Reset |
Mechanical
| Parameter | Value |
|---|---|
| Dimensions | 220L × 220W × 45H (mm) |
| Color | White |
| Weight | 0.3KG |
| Mounting Type | Ceiling, Wall, or Stand Rack |
