Model no – TRI-ACV-CPW-1001
The TRI-ACV-CPW-1001 is a digital networked DSP (Digital Signal Processing) wireless conference processor from TRISTAR. It utilizes 5G Wi-Fi for wireless communication, supporting up to 250 wireless units and offering high-fidelity audio quality with lossless transmission. It also includes features like a 16-level equalizer, USB recording, and noise cancellation.
| Parameter | Value |
|---|---|
| Power | 100V / 240V AC |
| Static Power Consumption | 12W |
| Maximum Power Consumption | 150W |
| Frequency Response | 20Hz ~ 20KHz |
| Noise Ratio (S/N) | >96dBA |
| Total Harmonic Distortion | <0.05% |
| Channel Crosstalk | >85dB |
| Dynamic Range | >94dB |
| RS-232 Control | 1×9-pole Sub-D female socket, 1×9-pole Sub-D male socket |
| Ethernet Control | RJ45 connected to PC |
| Mounting | 19″ standard rack |
| Dimensions (mm) | 481L × 265W × 46H |
| Weight | 3kg |
| Color | Black |
