Description
|
Parameter |
Value |
||||
|
Mono Input Channel |
6 channels |
||||
|
Stereo Input Channel |
2 channels (selectable. If selected, mono channels will be lessened 4 channels) |
||||
|
Mono Insert Channel |
6 channels |
||||
|
Phantom Power for MIC |
+48V |
||||
|
Output Channel |
2 main output channels; 2 REC output channels; 1 effects output channels; 1 monitor output channel; 1 stereo headphone output channel |
||||
|
Frequency Response |
20~20KHz ±1dB |
||||
|
Max Gain of Mono MIC to Main Output |
50dB±3dB |
||||
|
Max Gain of Mono Line to Main Output |
30dB±3dB |
||||
|
Max Gain of Stereo Line to Main Output |
30dB, 3dB(Optional) |
||||
|
Channel Crosstalk |
≥80dB @ 1KHz |
||||
|
S/N Ratio (Weighted) |
78dB @ 1KHz 0dB |
||||
|
Max Balance Output of Main Output Channel |
22dB±1.5dB |
||||
|
Max Unbalance Group Output/Main Output Channel |
16dB±1.5dB, without group |
||||
|
REC Max Unbalance Output |
16dB±1.5dB |
||||
|
Monitor Max Unbalance Output |
16dB±1.5dB |
||||
|
Effects Max Unbalance Output |
16dB±1.5dB |
||||
|
Headphone Output |
12dB±1.5dB @ 1KHz 32Ω |
||||
|
Gain Difference between Channels |
≤2dB |
||||
|
THD |
≤0.02% @ 0dB 1KHz |
||||
|
Mono Channel EQ |
|||||
|
High Frequency, Intermediate Frequency, Low Frequency |
12KHz, 1.8KHz , 80Hz |
||||
|
Center Frequency Deviation and Gain |
Frequency deviation <8%, Max gain: ±15dB |
||||
|
Stereo Channel EQ |
|||||
|
High Frequency, Intermediate Frequency, Low Frequency |
12KHz, 1.8KHz , 80Hz |
||||
|
Center Frequency Deviation and Gain |
Frequency deviation <8%, Max gain: ±15dB |
||||
|
Stereo Channel EQ |
|||||
|
High Frequency, Intermediate Frequency, Low Frequency |
12KHz, 1.8KHz, 80Hz |
||||
|
Center Frequency Deviation and Gain |
Frequency deviation <8%, Max gain: ±15dB |
||||
|
7 GEQ of Main Output |
|||||
|
Center Frequency |
63Hz,160Hz,400Hz,1KHz,2.5KHz,6.3KHz,16KHz |
||||
|
Frequency Deviation and Gain |
±12dB inaccuracy 2dB, Frequency deviation ≤8% |
||||
|
Effectors |
21 kinds of DSP effects: HALL, ROOM, PLATE, AMBIENT, GATED, REVERS, VOICE, DEL&REV, ECHO 40, ECHO 50, DELAY, CHORUS, CHO&DEL, CHO&REV, FLANGER, FLA&DEL, FLA&REV, TREMOLO, TRE&REV, WAH WAH, WAH&REV |
||||
|
Clipping Indicator Light |
Indicator 3dB earlier than clipping level |
||||
|
12 Levels Indicator Light of Main Outputs |
+9dB, +6dB, +3dB, 0dB, -2dB, -4dB, -6dB, -9dB, -12dB, -16dB, -18dB, -21dB |
||||
|
Power Supply & Power Consumption |
~220-240V 50/60Hz, <70W |
||||
|
Output Power of Amplifier |
|||||
|
Dimension of External Power Supply |
129×90×77mm |
||||
|
Dimension(W×D×H) |
327.5×389.7×80.3mm |
||||
|
Net Weight |
5Kg |
||||
