Description
|
Parameter |
Value |
||
|
Amplifier Section (Load 100V Output) |
Rated Output Power (THD 1%) |
240W |
|
|
Speaker Zone 1~6 Output |
50W MAX |
||
|
Mic Input Section (Mic 1~4 In@1KHz) |
Input Sensitivity/Impedance |
5mV 600Ω/350mV 10KΩ BAL |
|
|
S/N Ratio |
Better than 75dB |
||
|
Frequency Response (±3dB) |
80Hz~16KHz |
||
|
Tone Control (Bass:100Hz, Treble:10KHz) |
±10dB |
||
|
Phantom Power |
+ 48V |
||
|
Line Input Section (Mic 1~2 In@1KHz) |
Input Sensitivity/Impedance |
350mV/47KΩ |
|
|
S/N |
Better than 80dB |
||
|
Frequency Response (±3dB) |
80Hz~16KHz |
||
|
Tone Control (Bass: 100Hz,Treble:10KHz) |
±10dB |
||
|
Tel Audio Input |
Input Sensitivity/Impedance |
0.775V/10KΩ |
|
|
S/N |
Better than 75dB |
||
|
Frequency Response (±3dB) |
80Hz~16KHz |
||
|
EMC Audio Input |
Input Sensitivity/Impedance |
0.775V/10KΩ |
|
|
S/N |
Better than 75dB |
||
|
Frequency Response (±3dB) |
80Hz~16KHz |
||
|
Pre Amp Out(Mic 1~4, Line 1~2, Tel In, Remote In) |
1V/600Ω |
||
|
Remote MIC Sensitivity/Impedance |
775mV/10KΩ |
||
|
THD |
Less than 0.1% at 1KHz, 1/3 rated power |
||
|
Power Supply |
~110V/60Hz or ~230V/50Hz & DC 24V |
||
|
Power Consumption |
380W |
||
