Description
|
Parameter |
Value |
|||
|
Technical |
||||
|
HDMI Compliance |
HDMI 2.1 |
|||
|
HDCP Compliance |
HDCP 2.3 |
|||
|
Video Bandwidth |
48Gbps |
|||
|
Video Resolution |
Up to 8K60Hz 4:2:0, 8K30Hz 4:4:4 and 4K120Hz 4:4:4 |
|||
|
Color Space |
RGB_4:4:4, YCbCr_4:4:4, YCbCr_4:2:2, YCbCr_4:2:0 |
|||
|
Color Depth |
8/10/12-bit |
|||
|
HDR Formats |
HDR, HDR10, HDR10+, Dolby Vision, HLG |
|||
|
Audio Formats |
HDMI IN/OUT: LPCM, Dolby DigitalPlus/EX, Dolby True HD, Dolby Atmos, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD AUDIO BREAKOUT: Optical Outputs: LPCM 2.0CH / Dolby / DTS 5.1CH Balanced Analog Audio Outputs: LPCM 2CH |
|||
|
Connection |
||||
|
Input Ports |
8 × HDMI INPUT (Type A, 19-pin female) |
|||
|
Output Ports |
8 × HDMI OUTPUT (Type A, 19-pin female) 8 × OPTICAL AUDIO OUT (S/PDIF) 8 × AUDIO OUT (5pin-3.81mm phoenix connector) |
|||
|
Control Ports |
1 × TCP/IP (RJ45) 1 × RS-232 (D-Sub 9) 1 × IR EXT (3.5mm stereo mini-jack) |
|||
|
Mechanical |
||||
|
Housing |
Metal Enclosure |
|||
|
Color |
Black |
|||
|
Dimensions |
440mm (W) × 203mm (D) × 44.5mm (H) |
|||
|
Weight |
2.94kg |
|||
|
Power Supply |
Input: AC 100–240V 50/60Hz, Output: DC 24V/3.75A (US/EU standard, CE/FCC/UL certified) |
|||
|
Power Consumption |
70W (Max) |
|||
|
Operating Temperature |
32–104°F / 0–40°C |
|||
|
Storage Temperature |
-4–140°F / -20–60°C |
|||
|
Operating Humidity |
20–80% relative humidity, non-condensing |
|||
|
Storage Humidity |
10–90% relative humidity, non-condensing |
|||
