Description
|
Parameter |
Value |
||||
|
Input connectors |
1× HDMI 2.0（IN&LOOP） 2× HDMI 1.3 1× 3G-SDI（IN&LOOP） 1× 10G OPT Port（OPT1） 1× USB3.0 |
||||
|
Output connectors |
10× Ethernet Ports 1× HDMI1.3 1× HDMI 2.0 LOOP 1× 3G-SDI LOOP 2× OPT |
||||
|
Loading Capacity |
6.5 million pixels |
||||
|
Max Width (pixels) |
10240 |
||||
|
Max Height (pixels) |
8192 |
||||
|
Layers |
6 *2K ×1K |
||||
|
Presets |
256 |
||||
|
Control Connectors |
2× Ethernet Port 1× USB |
||||
|
Electrical Parameters |
Power connector |
100-240V~, 50/60Hz, 2A-0.8A |
|||
|
Rated power consumption |
44 W |
||||
|
Operating Environment |
Temperature |
0°C to 50°C |
|||
|
Humidity |
5% RH to 85% RH, non-condensing |
||||
|
Storage Environment |
Temperature |
–10°C to +60°C |
|||
|
Humidity |
5% RH to 95% RH, non-condensing |
||||
|
Physical Specifications |
Dimensions |
482.6 mm × 302.2 mm × 50.1 mm |
|||
|
Net weight |
3.9 kg |
||||
|
Total weight (packed with paper box) |
6.5 kg |
||||
|
Total weight (packed with flight case) |
9.2 kg |
||||
|
Accessories (Optional) |
1x Remote control |
||||
|
Noise Level (typical at 25°C/77°F) |
45 dB (A) |
||||
