Description
|
Parameter |
Value |
|
|
Basic Parameters |
Size (inch) |
108 |
|
Display Ratio |
16:9 |
|
|
Resolution (W*H) |
1920 (H) x1080(V) |
|
|
Pixel Pitch (mm) |
1.25 |
|
|
Visible Area (m²) |
3.24 |
|
|
Dimensions (mm) |
2411 × 1476 × 30.4 |
|
|
Thickness (mm) |
30.4 (without wall-hung) / 52.4 (with wall-hung) |
|
|
Planeness (mm) |
≤ 0.1 |
|
|
Weight (kg) |
80 |
|
|
Material |
Die-cast Aluminum |
|
|
Border Material / Colour |
Aluminum Profile / Black |
|
|
Maintenance |
Front |
|
|
Installation Method |
Wall-mounting / Mobile stand |
|
|
Display Parameters |
LED Type |
COB |
|
LED Life Time (Hrs) |
≥ 100000 |
|
|
Horizontal / Vertical Viewing Angle (degree) |
H: 170° / V: 160° |
|
|
Brightness (cd/㎡) |
600 (adjustable) |
|
|
Refresh Rate (Hz) |
3840 |
|
|
Video Frame Rate (Hz) |
50 / 60 |
|
|
Processing Depth (bit) |
19 |
|
|
Contrast Ratio |
10000 : 1 |
|
|
Color Temperature (K) |
2000K – 9500K |
|
|
Pixel Level Brightness Calibration |
Support |
|
|
Pixel Level Color Calibration |
Support |
|
|
Brightness Uniformity |
≥ 98% |
|
|
Color Uniformity |
±0.003 Cx, Cy or less |
|
|
Mainboard Parameters |
Operating System |
Android 13.0 |
|
CPU |
Cortex A73 × 4 + A53 × 4 |
|
|
RAM / ROM |
8GB DDR4 / 64GB |
|
|
Interface |
SPDIF × 1 / USB 2.0 × 1 / HDMI IN × 2 / USB 3.0 × 3 / USB-D × 1 / Audio out × 1/ LAN × 2 / RS232 × 1 |
|
|
WiFi |
WiFi 5 + WiFi 6 (Dual WiFi) |
|
|
Parameter |
Value |
|
|
Speaker |
Bluetooth |
5.0 |
|
Remote Control |
Support |
|
|
Fixed Mode |
Built-in |
|
|
Rated Power |
20W × 2 |
|
|
Operation Parameters |
Input Voltage |
AC 100V – 240V, 50–60Hz |
|
Standby Power Consumption (W) |
≤ 0.8 |
|
|
Average Power Consumption (W) |
524 |
|
|
Peak Power Consumption (W) |
892 |
|
|
Operating Temperature / Humidity |
−10°C ~ +45°C / 10–80% RH |
|
|
Storage Temperature / Humidity |
−20°C ~ +50°C / 10–70% RH |
|
|
Category Of Accessories |
Name |
Quantities |
|
Standard Fittings |
Remote Controls |
1 PC |
|
U-disk |
1 PC |
|
|
Manual Vacuum Suction Cup |
1 PC |
|
|
Spare Parts Module |
2 PCS |
|
|
Other Spare Parts |
Several (see shipment list for details) |
|
|
Warranty Card |
1 PC |
|
|
Certificate |
1 PC |
|
|
Instructions |
1 PC |
|
|
Optional Accessories |
Mobile Bracket |
1 PC |
|
Dongle (Type-C) |
Choose according to the required quantity |
PRODUCT ACCESSORIES :
