Description
| Input Interface | Rj45 Connector 7 |
| Output Interface | HDMI-A Interface |
| Supported Protocols | HDMI 1.4a, HDCP1.3, HDCP2.2, EDID 1.4 |
| Pixel Bandwidth | More Than 225mhz, Full Digital |
| Interface Bandwidth | More Than 6.75gbps |
| Supported Resolution | 1080p/60 Deep Color
Upto 3840 X 2160 / 30 Hz |
| Signal Type | HDMI I.4a/T.M.D. SÂ Full Digital Signal |
| Signal Strength | T.M.D.S. +/-0.4 Vpp |
| Minimum/ Maximum Level | T.M.D.S. 2.9v/3.3v |
| Audio Input | HDMI & Analog |
| Impedance | The Difference Of 100 |
| Serial Port Control | Rs-232 (BI Directional) |
| Baud Rate | Maximum 5mv |
| Infrared Control | Ir 3.5mm |
| Ir Frequency | 38khz |
| Maximum Distance | 100 Meter Through CAT6 |
| Remote Power | Support POC (Power Over Cable) function, it means that either the transmitter or receiver is connected to 12V/1A power supply, the other doesn’t need power supply |
