Description
|
Parameter |
Value |
|
|
HDMI version |
HDMI2.0b |
|
|
HDCP version |
HDCP 2.2 |
|
|
Video bandwidth |
600MHz/18Gbps |
|
|
Video resolution |
480i ~1080p50/60Hz, 4Kx2K@24/30Hz, 4k2k@60Hz |
|
|
Video color space |
RGB, YCbCr 4:4:4, YCbCr 4:2:2 |
|
|
HDMI audio format |
LPCM 7.1 CH, Dolby TrueHD, and DTS-HD Master Audio |
|
|
Input interface |
1 xHDMI Type A [19-pin female port], 1 xSERVICE [Micro USB, upgrade port] |
|
|
Output interface |
4 x HDMI Type A [19-pin female port] |
|
|
The recommended maximum output distance |
Transmission 4K/60Hz YUV 4:4:4, the cable is less than 5m; transmission 4K/30Hz /8-bit, the cable is less than 10m; transmission 1080P/60Hz /8-bit the cable is less than 15m· |
|
|
Cover |
Black metal |
|
|
Size |
63mm (W) x 163mm (D) x 16mm (H) |
|
|
Weight |
260g |
|
|
Power supply |
5V/1A DC (US/EU standards,CE/FCC/UL certified) |
|
|
Power consumption |
2W |
|
|
Working temperature and humidity |
0°c – 40° C / 32°F – 104°F; 20-90% RH (non-condensing) |
|
|
Storage temperature and humidity |
-20° C – 60° C / -4°F – 140°F ; 20-90% RH (non-condensing) |
|
