Description
|
Parameter |
Value |
|
|
HDMI version |
HDMl2.0a, DVI 1.0 |
|
|
HDCP version |
HDCP 2.2 |
|
|
Video bandwidth |
18Gbps |
|
|
Video resolution |
480i ~1080p50/60Hz, 4Kx2K@24/30Hz, 4k2k@60Hz |
|
|
Video color space |
RGB, YCbCr 4:4:4, YCbCr 4:2:2 |
|
|
HDMI audio format |
PCM 2CH, LPCM 7.1/5.1CH, Dolby Digital, DTS 5.1, Dolby Digital+, Dolby TrueHD, DTS-HD Master Audio, Dolby Atmos and DTS:X |
|
|
Input interface |
1 xHDMI Type A [19-pin female port], 1 xSERVICE [Micro USB, upgrade port] |
|
|
Output interface |
8xHDMI Type A [19-pin female port] |
|
|
The recommended maximum output distance |
Transmission 4K/60Hz YUV 4:4:4, the cable is less than 5m; transmission 4K/30Hz /8-bit, the cable is less than 10m; transmission 1080P/60Hz /8-bit the cable is less than 15m. |
|
|
Cover |
Black metal |
|
|
Size |
243mm (length) x 102mm (width) x 16mm (height) |
|
|
Weight |
572g |
|
|
Power supply |
Input: AC 100~240V 50/60Hz; Output: DC 12V/1A (US/EU standard, CE/FCC/UL certification) |
|
|
Power consumption |
6.15W |
|
|
Working temperature and humidity |
-10″C – 50″C / 14″F ~ 122″F; 20-90% RH (non-condensing) |
|
|
Storage temperature and humidity |
-20°C – 60°C / -4°F – 140°F; 20-90% RH (non-condensing) |
|
