Description
|
Parameter |
Value |
|
|
HDMI version |
HDMl2.0a, DVI 1.0 |
|
|
HDCP version |
HDCP 2.2, HDCP 1.4 |
|
|
Video bandwidth |
18Gbps |
|
|
Video resolution |
Up to 4Kx2K@60Hz |
|
|
Highest pixel clock |
600MHz |
|
|
Interface |
4 HDMI input ports, 1 HDMI output port, 1 IR receiving port and 1 RS232 port |
|
|
HDMI Audio Output |
PCM2.1/5.1/7.1 CH.Dolby5.1,DTS5.1, Dolby-TrueHD,DTS-HD |
|
|
Dimensions(mm) |
180(D)x85(W)x11.6(H) |
|
|
Weight(g) |
300 |
|
|
Housing |
Black metal |
|
|
Power Consumption |
Max2.5W |
|
|
Operating Temperature |
0°C~40’C/32°F~104°F |
|
|
Storage Temperature |
-20°C-60’C/-4 °F-140°F |
|
|
Working humidity |
0~95% R H |
|
|
Power supply |
DC 5V |
|
