Description
|
Parameter |
Value |
|
Input Video Signal |
VGA; HDMI (4K@60Hz YUV 4:2:0, HDCP 2.2) |
|
Interface |
1 x VGA IN, 1 x VGAAUDIO, 1 x HDMI IN, 1 x UPDATE, 1 x HDBT OUT, 1 x POWER IN (2 Pins, 3.5mm Phoenix Connector), 1 x POWER OFF (2 Pins, 3.5mm Phoenix Connector), 1 x RS232 (3 Pins, 3.5mm Phoenix Connector),1 x IR OUT (2 Pins , 3.5mm Phoenix Connector ) |
|
Input Resolutions |
VGA: Up to 1920×1200 HDMI: VESA: 800×600, 1024×768, 1280×768, 1280×800, 1280×960, 1280×1024, 1360×768, 1366×768, 1440×900, 1600×9008, 1600×1200,1680×1050, 1920×1200, 2560×1440, 2560×1600 SMPTE: 1280x720P8, 1920×1080168 1920x1080P, 3840×21602.3,5,8, 4096×21602,3,5,8 1 = at 23.98 Hz, 2 = at 24 Hz, 3 = at 25 Hz, 4 = at 29.97 Hz, 5 = at 30 Hz, 6 = at 50 Hz, 7 = at 59.94 Hz, 8 = 60 Hz Note: 4096×2160/3840×2160@50Hz/60Hz is based on chroma sub-sampling 4:2:0 8bit only. |
|
Output Video Signal |
HDBaseT 1.0 |
|
Input Resolutions |
1600×900, 1600×1200, 1680×1050 1920x1080P, 1920×1200, 2560×1440, 2560×1600, 3840×21602,3,5,8 3.5,8 4096×21602.3,5,8 1 = at 23.98 Hz, 2 = at 24 Hz, 3 = at 25 Hz, 4 = at 29.97 Hz, 5 = at 30 Hz, 6 = at 50 Hz, 7 = at 59.94 Hz, 8 = 60 Hz Note: 4096×2160/3840×2160@50Hz/60Hz is based on chroma sub-sampling 4:2:0 8-bit only. |
|
Audio Format |
HDMI: Supports multi-channel audio formats, including PCM 2.0/5.1/7.1, Dolby TrueHD, Dolby Atmos, DTS-HD Master Audio and DTS:X VGA Audio : Stereo |
|
Maximum Data Rate |
10.2Gbps |
|
Control Method |
Automatic switching, front panel button |
|
Operating/storage Temperature |
0°C to 45°C (32°F to 113°F), -20°C to 70°C (-4°F to 158°F) |
|
Humidity |
10% to 90%, non-condensing |
|
ESD Protection |
+8kV(Air-gap discharge)/ ±4kV(Contact discharge) |
|
Power Consumption (Max) |
3.9W, transmitter powers receiver |
|
Power Supply |
PoC, powered by receiver, or local power supply through the 12V phoenix connector |
|
Device Dimension (Wx Hx D) |
89mm x 38.4mm x 105.6mm/3.5″ x 1.51″ x 4.16″ |
|
Product Weight |
0.3kg/0.66lb |
